MSRP : $ 119.26
TYPE 2024 Standard Stroke Piggy-Back Plus Kit
2024 2.5” Standard Stroke Piggy-Back plus Kit
Product Name: DuraMax DMD2024DP Piggy Back Plus Kit
Part Number: 21500-CAG00
Service Brake Size: 20
Parking Brake Size: 24
Air Port Size: 3/8-18 NPTF
Max. Operating Air Pressure: 150 psi
Piggy Plus Kit Included:
- Piggy Back Unit - Long Life Super High-Force Power Spring Contained.
- Special Deep Lock-In Design Clamp Band,
- Heavy-Duty Nylon Reinforced Diaphragm
- Reinforced Design Cover Head Housing
- Deep Lock-in Design Clamp Band
- Heavy Duty Nylon Fabric Reinforced Diaphragm
- Non Coil-Clash Long Life Super High-Force Power Spring
- Tamper Resistant Design
- Nitrile Rubber Push-Rod Seal and Guide
- Corrosion Resistance e-Coating Standard (Special Atmospheric additional Top Coat Optional)
- Advanced Threaded Technology Aluminum Alloy Adopt Housing
| DMD 2024DP | |
|---|---|
| SIZE | 2024 |
| STROKE | 2.5" (63.5mm) |
| Wt. lb (kg) | 11.01lb(4.99kg) |
| 1 | 10.19"/258.8mm |
| 2 | 6.70"/170mm |
| 3 | 1.97"/50mm |
| 4 | 1.14"/29mm |
| 5 | 6.5"/165.mm |
| 6 | 7.34"/186.43mm |
| 7 | N/A |
| A (PORT) | 3/8 -18NPTF |
| B (MTG BOLT) | N/A |
| C (P/ROD) | N/A |
| HOLD-OFF | 6.2bar/89.9psi |
Note
1. DIMENSION "4" MEASURED WITH MAIN SPRING COMPRESSED PNEUMATICALLY2. PRODUCT PERFORMANCE MEET SAE J2318 STANDARD.
3. PRODUCT COMPLIANCE TO FMVSS121 REGULATIONS
| DURAMAX MODEL |  |
 |
 |
 |
|
| Model | Part No | ||||
| DMD2024DP Standard Stroke Piggy Back Plus Kit) | TR2024L PG | 3420008 | GP2024 | ||
